Specifications
- Turn On Delay Time
- 6.6 ns
- Drain Currentmax Abs Id
- 10.1A
- Case Connection
- DRAIN SOURCE
- Fet Feature
- Standard
- Input Capacitance Ciss Max Vds
- 608pF @ 15V
- Kurşunsuz Kodu
- yes
- Current Continuous Drain Id25
- 10.1A 12.4A
- Operating Mode
- ENHANCEMENT MODE
- Terminal Sayısı
- 6
- Transistor Application
- SWITCHING
- Number Of Elements
- 2
- Jesd30 Code
- R-PDSO-N6
- Gate To Source Voltage Vgs
- 20V
- Rds On Max Id Vgs
- 20m Ω @ 10.1A, 10V
- Ds Breakdown Voltagemin
- 30V
- Turn Off Delay Time
- 17.4 ns
- Terminal Formu
- NO LEAD
- Pin Sayısı
- 8
- Fall Time Typ
- 1.5 ns
- Seri
- PowerTrench®
- Drain To Source Voltage Vdss
- 30V
- Montaj Tipi
- Sub-Base Mount
- Montaj
- Surface Mount
- Lifecycle Status
- ACTIVE (Last Updated: 1 week ago)
- Max Power Dissipation
- 2.5W
- Maks. Çalışma Sıcaklığı
- 150°C
- Feedback Capmax Crss
- 31 pF
- Min. Çalışma Sıcaklığı
- -55°C
- Rise Time
- 1.8ns
- Fet Type
- 2 N-Channel (Half Bridge)
- Number Of Channels
- 2
- Vgsth Max Id
- 3V @ 250μA
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- RoHS Durumu
- ROHS3 Compliant
- Power Max
- 1W
- Fet Technology
- METAL-OXIDE SEMICONDUCTOR
- Fabrika Tedarik Süresi
- 16 Weeks
- Parça Durumu
- Active
- Continuous Drain Current Id
- 12.4A
- Gate Charge Qg Max Vgs
- 11nC @ 10V
