Specifications
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Qualification Status
- COMMERCIAL
- Turn Off Time
- 44 μs
- RoHS Durumu
- ROHS3 Compliant
- Voltage Load
- 6.4V~14V
- Output Configuration
- Half Bridge
- Fault Protection
- Shoot-Through, UVLO
- Parça Durumu
- Obsolete
- Fonksiyon Sayısı
- 1
- Ambalaj
- Tape & Reel (TR)
- Genişlik
- 8mm
- Kılıf / Paket
- 56-PowerWFQFN Module
- Current Peak Output
- 65A
- Montaj Tipi
- Surface Mount
- Applications
- Synchronous Buck Converters
- Özellikler
- Bootstrap Circuit
- Uzunluk
- 8mm
- Besleme Gerilimi
- 12V
- Maks. Oturma Yüksekliği
- 0.8mm
- Jesd30 Code
- S-XQCC-N56
- Yüzey Montaj
- YES
- Terminal Adımı
- 0.5mm
- Interface
- PWM
- Terminal Formu
- NO LEAD
- Pin Sayısı
- 56
- Temel Parça No
- FDMF8705
- Turn On Time
- 56 μs
- REACH Uyumluluk Kodu
- unknown
- Tedarikçi Cihaz Paketi
- 56-Power88™
- Besleme Gerilimi
- 6.4V~13.5V
- Load Type
- Inductive
- Terminal Sayısı
- 56
- Terminal Pozisyonu
- QUAD
- Current Output Channel
- 18A
- Çalışma Sıcaklığı
- -55°C~150°C TJ
- High Side Driver
- YES
