Specifications
- Besleme Gerilimi
- 10V~20V
- REACH Uyumluluk Kodu
- not_compliant
- Kılıf / Paket
- 36-SMD Module
- Terminal Formu
- UNSPECIFIED
- Lifecycle Status
- ACTIVE (Last Updated: 1 week ago)
- Input Voltagenom
- 50V
- Tepe Reflow Sıcaklığı (°C)
- NOT SPECIFIED
- Montaj
- Surface Mount
- Interface
- PWM
- Input Voltage Min
- 3V
- Uzunluk
- 7.5mm
- RoHS Durumu
- ROHS3 Compliant
- Rds On Typ
- 7.3m Ω LS, 7.7m Ω HS
- Özellikler
- Bootstrap Circuit
- Terminal Pozisyonu
- UNSPECIFIED
- Jesd30 Code
- R-XXMA-X37
- Fonksiyon Sayısı
- 1
- Kurşunsuz Kodu
- yes
- Tepe Reflow Süresi (maks. sn)
- NOT SPECIFIED
- Weight
- 145.646mg
- Load Type
- Inductive, Capacitive
- Ambalaj
- Tape & Reel (TR)
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Applications
- DC Motors, General Purpose
- Control Technique
- PULSE WIDTH MODULATION
- Montaj Tipi
- Surface Mount
- Yayın Yılı
- 2016
- Input Voltage Max
- 80V
- Switcher Configuration
- BUCK-BOOST
- Çalışma Sıcaklığı
- -40°C~125°C TJ
- Output Configuration
- Half Bridge
- Analog Ic Other Type
- SWITCHING CONTROLLER
- Fabrika Tedarik Süresi
- 16 Weeks
- Voltage Load
- 3V~80V
- Terminal Kaplaması
- Tin (Sn)
- Terminal Sayısı
- 37
- Maks. Oturma Yüksekliği
- 0.8mm
- Parça Durumu
- Active
- Fault Protection
- UVLO
- JESD-609 Kodu
- e3
