Volume pricing
- 1+ pcs$3.15
- 10+ pcs$2.97
- 100+ pcs$2.81
- 500+ pcs$2.65
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Terminal Sayısı
- 4
- Radyasyon Dayanımı
- No
- RoHS Durumu
- ROHS3 Compliant
- Lifecycle Status
- ACTIVE (Last Updated: 1 day ago)
- Voltage Forward Vf Max If
- 1.1V @ 25A
- Max Surge Current
- 300A
- Parça Durumu
- Active
- Kurşunsuz
- Lead Free
- Kurşunsuz Kodu
- yes
- Weight
- 7g
- Average Rectified Current
- 25A
- Montaj
- Through Hole
- Additional Feature
- UL RECOGNIZED
- Kılıf / Paket
- 4-SIP, TS-6P
- Ambalaj
- Tube
- Montaj Tipi
- Through Hole
- Reverse Voltage Dc
- 420V
- Max Forward Surge Current Ifsm
- 350A
- Fabrika Tedarik Süresi
- 11 Weeks
- Number Of Elements
- 1
- Peak Nonrepetitive Surge Current
- 350A
- Diode Element Material
- SILICON
- Diode Type
- Single Phase
- Number Of Phases
- 1
- Element Configuration
- Single
- Max Repetitive Reverse Voltage Vrrm
- 600V
- Terminal Kaplaması
- Tin (Sn)
- Case Connection
- ISOLATED
- Pin Sayısı
- 4
- JESD-609 Kodu
- e3
- Forward Voltage
- 1.1V
- Current Reverse Leakage Vr
- 10μA @ 600V
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Çalışma Sıcaklığı
- -55°C~150°C TJ
- Peak Reverse Current
- 10μA
- Yayın Yılı
- 2016
- Forward Current
- 25A
- ECCN Kodu
- EAR99
