Specifications
- Parça Durumu
- Obsolete
- Max Collector Current
- 20mA
- Rise Time
- 10μs
- Çalışma Sıcaklığı
- -30°C~85°C
- Forward Voltage
- 1.1V
- Power Dissipation
- 75mW
- Output Voltage
- 20V
- Collector Emitter Voltage Vceo
- 20V
- Pin Sayısı
- 4
- Terminal
- Solder
- Number Of Channels
- 1
- Montaj Tipi
- Surface Mount
- Genişlik
- 4mm
- Algılama Mesafesi
- 0.079 (2mm)
- JESD-609 Kodu
- e1
- Output Configuration
- Phototransistor
- Turn On Delay Time
- 10 μs
- Tip
- Unamplified
- Reverse Breakdown Voltage
- 5V
- Sensing Method
- Through-Beam
- Kurşunsuz
- Lead Free
- Reverse Voltage Dc
- 5V
- Fabrika Tedarik Süresi
- 4 Weeks
- Reach Svhc
- Unknown
- Collectoremitter Saturation Voltage
- 400mV
- Kılıf / Paket
- 4-SMD
- Forward Current
- 25mA
- Input Current
- 5mA
- Yükseklik
- 4mm
- Fall Time Typ
- 10 μs
- Uzunluk
- 5mm
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Ambalaj
- Cut Tape (CT)
- Onstate Collector Currentnom
- 0.15mA
- Kurşunsuz Kodu
- yes
- Response Time
- 10μs, 10μs
- RoHS Durumu
- RoHS Compliant
- Yayın Yılı
- 2002
- Montaj
- PCB, Surface Mount
- Terminal Kaplaması
- Tin/Silver/Copper (Sn/Ag/Cu)
