Volume pricing
- 1+ pcs$0.40
- 10+ pcs$0.38
- 100+ pcs$0.36
- 500+ pcs$0.34
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Fonksiyon Sayısı
- 1
- Max Output Current
- 30mA
- Yayın Yılı
- 2002
- Montaj
- PCB, Through Hole
- RoHS Durumu
- RoHS Compliant
- Slot Widthnom
- 3mm
- Wavelength Peak
- 950 nm
- Collectoremitter Breakdown Voltage
- 30V
- Yükseklik
- 5.6mm
- Forward Current
- 50mA
- Input Current
- 50mA
- Reach Svhc
- Unknown
- Kılıf / Paket
- PCB Mount
- Fabrika Tedarik Süresi
- 11 Weeks
- Kurşunsuz Kodu
- yes
- Response Time
- 10μs, 10μs
- Onstate Collector Currentnom
- 0.2mA
- Ambalaj
- Bulk
- Nem Hassasiyeti (MSL)
- Not Applicable
- Fall Time Typ
- 10 μs
- Uzunluk
- 6.4mm
- Tip
- Unamplified
- Reverse Breakdown Voltage
- 5V
- Output Configuration
- Phototransistor
- Algılama Mesafesi
- 0.118 (3mm)
- Montaj Tipi
- Through Hole
- Number Of Channels
- 1
- Genişlik
- 4.2mm
- Max Input Current
- 50mA
- Reverse Voltage Dc
- 5V
- Kurşunsuz
- Lead Free
- Sensing Method
- Through-Beam
- Output Voltage
- 30V
- Forward Voltage
- 1.3V
- Çalışma Sıcaklığı
- -25°C~85°C
- Rise Time
- 10μs
- Power Dissipation
- 80mW
- Parça Durumu
- Active
- Max Collector Current
- 30mA
- Ambient Temperature Range High
- 85°C
