Volume pricing
- 1+ pcs$0.85
- 10+ pcs$0.81
- 100+ pcs$0.76
- 500+ pcs$0.72
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Ambalaj
- Bulk
- Onstate Collector Currentnom
- 0.5mA
- Response Time
- 4μs, 4μs
- Kurşunsuz Kodu
- yes
- Fall Time Typ
- 4 μs
- Nem Hassasiyeti (MSL)
- Not Applicable
- REACH Uyumluluk Kodu
- unknown
- Fabrika Tedarik Süresi
- 7 Weeks
- Kılıf / Paket
- PCB Mount
- Collectoremitter Breakdown Voltage
- 30V
- Slot Widthnom
- 3.4mm
- Current Dc Forward If Max
- 50mA
- Fonksiyon Sayısı
- 1
- RoHS Durumu
- RoHS Compliant
- Montaj
- Screw, Through Hole
- Yayın Yılı
- 2003
- Collector Emitter Voltage Vceo
- 30V
- Dark Currentmax
- 200nA
- Pin Sayısı
- 4
- Power Dissipation
- 100mW
- Rise Time
- 4μs
- Çalışma Sıcaklığı
- -25°C~85°C
- Max Collector Current
- 20mA
- Parça Durumu
- Active
- Sensing Method
- Through-Beam
- Forward Currentmax
- 0.05A
- Kurşunsuz
- Lead Free
- Algılama Mesafesi
- 0.134 (3.4mm)
- Output Configuration
- Phototransistor
- Tip
- Unamplified
- Additional Feature
- HIGH RELIABILITY
- Montaj Tipi
- Through Hole
