Specifications
- Montaj
- PCB, Through Hole
- Yayın Yılı
- 2003
- Voltage Rated Dc
- 30V
- RoHS Durumu
- RoHS Compliant
- Akım Değeri
- 20mA
- Fonksiyon Sayısı
- 1
- Max Output Current
- 20mA
- Slot Widthnom
- 3.4mm
- Wavelength Peak
- 940 nm
- Collectoremitter Breakdown Voltage
- 30V
- Kılıf / Paket
- PCB Mount
- Reach Svhc
- No SVHC
- Fabrika Tedarik Süresi
- 9 Weeks
- REACH Uyumluluk Kodu
- unknown
- Output Current
- 20mA
- Input Current
- 50mA
- Forward Current
- 50mA
- Nem Hassasiyeti (MSL)
- Not Applicable
- Fall Time Typ
- 4 μs
- Response Time
- 4μs, 4μs
- Onstate Collector Currentnom
- 0.5mA
- Ambalaj
- Bulk
- Genişlik
- 6.2mm
- Montaj Tipi
- Through Hole
- Number Of Channels
- 1
- Max Input Current
- 30mA
- Reverse Breakdown Voltage
- 4V
- Max Power Dissipation
- 100mW
- Tip
- Unamplified
- Output Configuration
- Phototransistor
- Algılama Mesafesi
- 0.134 (3.4mm)
- Kurşunsuz
- Lead Free
- Sensing Method
- Through-Beam
- Reverse Voltage Dc
- 4V
- Max Collector Current
- 20mA
- Parça Durumu
- Active
- Output Voltage
- 30V
- Power Dissipation
- 100mW
- Forward Voltage
- 1.2V
- Çalışma Sıcaklığı
- -25°C~85°C
