Volume pricing
- 1+ pcs$2.03
- 10+ pcs$1.92
- 100+ pcs$1.81
- 500+ pcs$1.70
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Nem Hassasiyeti (MSL)
- Not Applicable
- Uzunluk
- 10mm
- Fall Time Typ
- 4 μs
- Response Time
- 4μs, 4μs
- Kurşunsuz Kodu
- yes
- Ambalaj
- Bulk
- Onstate Collector Currentnom
- 1.2mA
- Kılıf / Paket
- PCB Mount
- Reach Svhc
- Unknown
- Fabrika Tedarik Süresi
- 7 Weeks
- Yükseklik
- 6.5mm
- Output Current
- 20mA
- Forward Current
- 50mA
- Slot Widthnom
- 3mm
- Collectoremitter Breakdown Voltage
- 30V
- Montaj
- PCB, Through Hole
- Yayın Yılı
- 2002
- RoHS Durumu
- RoHS Compliant
- Fonksiyon Sayısı
- 1
- Max Output Current
- 20mA
- Pin Sayısı
- 4
- Collector Emitter Voltage Vceo
- 30V
- Dark Currentmax
- 200nA
- Terminal
- Solder
- Radyasyon Dayanımı
- No
- Ambient Temperature Range High
- 85°C
- Max Collector Current
- 20mA
- Parça Durumu
- Active
- Power Dissipation
- 100mW
- Çalışma Sıcaklığı
- -25°C~85°C
- Rise Time
- 4μs
- Forward Voltage
- 1.2V
- Kurşunsuz
- Lead Free
- Sensing Method
- Through-Beam
- Reverse Voltage Dc
- 4V
- Genişlik
- 6.5mm
- Number Of Channels
- 1
- Montaj Tipi
- Through Hole
- Reverse Breakdown Voltage
- 4V
- Tip
- Unamplified
