Specifications
- RoHS Durumu
- RoHS Compliant
- Montaj
- PCB, Through Hole
- Yayın Yılı
- 2002
- Voltage Rated Dc
- 30V
- Fonksiyon Sayısı
- 1
- Collectoremitter Breakdown Voltage
- 30V
- Slot Widthnom
- 5mm
- Fabrika Tedarik Süresi
- 11 Weeks
- Kılıf / Paket
- PCB Mount
- Reach Svhc
- Unknown
- Input Current
- 30mA
- Forward Current
- 50mA
- Yükseklik
- 14.5mm
- Uzunluk
- 14mm
- Fall Time Typ
- 4 μs
- Nem Hassasiyeti (MSL)
- Not Applicable
- Onstate Collector Currentnom
- 0.5mA
- Ambalaj
- Bulk
- Response Time
- 4μs, 4μs
- Kurşunsuz Kodu
- yes
- Max Input Current
- 30mA
- Genişlik
- 5mm
- Montaj Tipi
- Through Hole
- Number Of Channels
- 1
- Output Configuration
- Phototransistor
- Algılama Mesafesi
- 0.197 (5mm)
- Reverse Breakdown Voltage
- 4V
- Max Power Dissipation
- 100mW
- Tip
- Unamplified
- Sensing Method
- Through-Beam
- Kurşunsuz
- Lead Free
- Reverse Voltage Dc
- 4V
- Max Collector Current
- 20mA
- Parça Durumu
- Active
- Power Dissipation
- 100mW
- Forward Voltage
- 1.2V
- Çalışma Sıcaklığı
- -25°C~85°C
- Rise Time
- 4μs
- Output Voltage
- 30V
- Collector Emitter Voltage Vceo
- 30V
