Volume pricing
- 1+ pcs$94.30
- 10+ pcs$88.96
- 100+ pcs$83.93
- 500+ pcs$79.18
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Electricallife
- 500,000 Cycles
- Release Force
- 500gf
- Contact Resistance
- 15mOhm
- Terminal Stili
- Screw Terminal
- Depth
- 21.7mm
- Fabrika Tedarik Süresi
- 2 Weeks
- Current Rating Amps
- 10A AC 6A DC
- ECCN Kodu
- EAR99
- Switch Type
- SNAP ACTING/LIMIT SWITCH
- Montaj
- Panel, Screw
- Yayın Yılı
- 2000
- Circuit
- SPDT
- Switch Function
- On-Mom
- Pozisyon Sayısı
- 2
- Throw Configuration
- SPDT, SPST
- Seri
- ZC
- Uzunluk
- 69.4mm
- Ingress Protection
- IP67 - Dust Tight, Waterproof
- Differential Travel
- 0.008 (0.2mm)
- Actuator Type
- Roller Plunger
- Max Voltage Rating Ac
- 480V
- Montaj Tipi
- Panel Mount
- Parça Durumu
- Active
- Akım Değeri
- 6A
- Operating Position
- 1.866 (47.4mm)
- Voltage Rated Dc
- 30V
- Mechanical Life
- 10,000,000 Cycles
- Operating Force
- 1200gf
- Terminal
- Screw
- Çalışma Sıcaklığı
- -10°C~80°C
- Ratings
- Dust Tight, IP67, Waterproof
- Overtravel
- 0.118 (3.0mm)
- Voltage Rated Ac
- 125V
- Pretravel
- 0.060 (1.5mm)
- Max Voltage Rating Dc
- 250V
- Genişlik
- 70mm
- Reach Svhc
- Unknown
- Orientation
- Straight
- RoHS Durumu
- RoHS Compliant
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
