Volume pricing
- 1+ pcs$14.99
- 10+ pcs$14.14
- 100+ pcs$13.34
- 500+ pcs$12.58
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Orientation
- Straight
- Overtravel
- 0.219 (5.6mm)
- Electricallife
- 500,000 Cycles
- Yayın Yılı
- 1998
- Seri
- Z
- RoHS Durumu
- RoHS Compliant
- Switch Type
- SNAP ACTING/LIMIT SWITCH
- Actuator Type
- Lever, Straight
- Genişlik
- 29.4mm
- Circuit
- SPDT
- ECCN Kodu
- EAR99
- Actuator Material
- Stainless Steel
- Switch Function
- On-Mom
- Terminal Stili
- Screw Terminal
- Depth
- 17.45mm
- Contact Current Rating
- 15A
- Operating Position
- 0.748 (19.0mm)
- Montaj Tipi
- Chassis Mount
- Uzunluk
- 74.6mm
- Max Current Rating
- 15A
- Reach Svhc
- Unknown
- HTS Kodu
- 8536.50.90.40
- Release Force
- 14gf
- Ambalaj
- Tray
- Ingress Protection
- IP00
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Terminal
- Screw
- Voltage Rated Ac
- 250V
- Akım Değeri
- 15A
- Voltage Rated Dc
- 30V
- Max Voltage Rating Ac
- 500V
- Operating Force
- 70gf
- Contact Materials
- Silver
- Max Voltage Rating Dc
- 250V
- Current Rating Amps
- 15A AC 6A DC
- Kurşunsuz
- Lead Free
- Differential Travel
- 0.050 (1.3mm)
- Number Of Poles
- 1
- Pozisyon Sayısı
- 2
- Fabrika Tedarik Süresi
- 10 Weeks
