Specifications
- Fabrika Tedarik Süresi
- 2 Weeks
- Montaj
- Chassis Mount, Panel
- Mechanical Life
- 10,000,000 Cycles
- Çalışma Sıcaklığı
- -15°C~80°C
- Parça Durumu
- Active
- Differential Travel
- 0.062 (1.6mm)
- Contact Ac Max Rating R Load
- 15A@250VAC
- Current Rating Amps
- 15A AC 6A DC
- Contact Materials
- Silver
- Operating Force
- 130gf
- Max Voltage Rating Dc
- 250V
- Voltage Rated Dc
- 30V
- Max Voltage Rating Ac
- 500V
- Body Height
- 39.4mm
- Voltage Rated Ac
- 125V
- Akım Değeri
- 6A
- Ambalaj
- Bulk
- Ingress Protection
- IP62
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Terminal
- Screw
- HTS Kodu
- 8536.50.90.40
- Release Force
- 21gf
- Max Current Rating
- 15A
- Uzunluk
- 81.6mm
- Operating Position
- 1.188 (30.2mm)
- Montaj Tipi
- Chassis Mount
- Contact Dc Max Rating R Load
- 15A@14VDC
- Depth
- 17.45mm
- Terminal Stili
- Screw Terminal
- Switch Function
- On-Mom
- Circuit
- SPDT
- ECCN Kodu
- EAR99
- Actuator Material
- Plastic, Stainless Steel
- RoHS Durumu
- RoHS Compliant
- Actuator Type
- Lever, Roller
- Switch Type
- SNAP ACTING/LIMIT SWITCH
- REACH Uyumluluk Kodu
- unknown
- Overtravel
- 0.158 (4.0mm)
- Electricallife
- 500,000 Cycles
- Yayın Yılı
- 2005
