Volume pricing
- 1+ pcs$20.15
- 10+ pcs$19.01
- 100+ pcs$17.94
- 500+ pcs$16.92
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- HTS Kodu
- 8536.50.90.40
- Release Force
- 28gf
- Ingress Protection
- IP62
- Terminal
- Screw
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Ambalaj
- Bulk
- Akım Değeri
- 6A
- Voltage Rated Ac
- 125V
- Body Height
- 25.5mm
- Voltage Rated Dc
- 30V
- Max Voltage Rating Ac
- 250V
- Max Voltage Rating Dc
- 250V
- Ratings
- IP00, IP62
- Contact Materials
- Silver
- Operating Force
- 160gf
- Differential Travel
- 0.040 (1.0mm)
- Contact Ac Max Rating R Load
- 15A@250VAC
- Current Rating Amps
- 15A AC 6A DC
- Weight
- 58g
- Çalışma Sıcaklığı
- -15°C~80°C
- Parça Durumu
- Active
- Mechanical Life
- 10,000,000 Cycles
- Montaj
- Chassis Mount, Panel, Screw
- Fabrika Tedarik Süresi
- 2 Weeks
- Orientation
- Straight
- Seri
- Z
- Yayın Yılı
- 2005
- Body Length Or Diameter
- 49.2mm
- Electricallife
- 500,000 Cycles
- Overtravel
- 0.079 (2.0mm)
- Actuator Type
- Lever, Straight
- Switch Type
- SNAP ACTING/LIMIT SWITCH
- REACH Uyumluluk Kodu
- unknown
- RoHS Durumu
- RoHS Compliant
- Circuit
- SPDT
- ECCN Kodu
- EAR99
- Contact Current Rating
- 15A
- Terminal Stili
- Screw Terminal
- Switch Function
- On-Mom
- Body Breadth
- 17.45 mm
