Volume pricing
- 1+ pcs$15.03
- 10+ pcs$14.18
- 100+ pcs$13.38
- 500+ pcs$12.62
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Orientation
- Straight
- Overtravel
- 0.062 (1.6mm)
- Electricallife
- 500,000 Cycles
- Body Length Or Diameter
- 49.2mm
- Yayın Yılı
- 2005
- Seri
- Z
- RoHS Durumu
- RoHS Compliant
- REACH Uyumluluk Kodu
- unknown
- Actuator Type
- Lever, Roller
- Switch Type
- SNAP ACTING/LIMIT SWITCH
- ECCN Kodu
- EAR99
- Circuit
- SPDT
- Terminal Stili
- Solder Lug
- Switch Function
- On-Mom
- Body Breadth
- 17.45 mm
- Contact Currentacmax
- 15A
- Contact Dc Max Rating R Load
- 15A@14VDC
- Operating Position
- 1.125 (28.6mm)
- Montaj Tipi
- Chassis Mount
- Release Force
- 14gf
- HTS Kodu
- 8536.50.90.40
- Ambalaj
- Bulk
- Terminal
- Solder
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Ingress Protection
- IP00
- Voltage Rated Ac
- 125V
- Akım Değeri
- 6A
- Body Height
- 25.5mm
- Contact Currentdcmax
- 15A
- Voltage Rated Dc
- 30V
- Max Voltage Rating Ac
- 250V
- Contact Materials
- Silver
- Operating Force
- 141gf
- Max Voltage Rating Dc
- 250V
- Differential Travel
- 0.050 (1.3mm)
- Contact Ac Max Rating R Load
- 15A@250VAC
- Current Rating Amps
- 15A AC 6A DC
- Fabrika Tedarik Süresi
- 2 Weeks
- Montaj
- Chassis Mount, Panel, Screw, Solder
- Mechanical Life
- 10,000,000 Cycles
