Specifications
- Circuit
- SPDT
- ECCN Kodu
- EAR99
- Actuator Type
- Lever, Roller
- Switch Type
- SNAP ACTING/LIMIT SWITCH
- REACH Uyumluluk Kodu
- unknown
- RoHS Durumu
- RoHS Compliant
- Seri
- Z
- Overtravel
- 0.094 (2.4mm)
- Electricallife
- 500,000 Cycles
- Body Length Or Diameter
- 49.2mm
- Yayın Yılı
- 2005
- Montaj Tipi
- Chassis Mount
- Operating Position
- 1.188 (30.2mm)
- Actuator Travel
- 2.4 mm
- Contact Currentacmax
- 0.1A
- Body Breadth
- 17.45 mm
- Terminal Stili
- Screw Terminal
- Switch Function
- On-Mom
- Contact Currentdcmax
- 0.1A
- Body Height
- 25.5mm
- Akım Değeri
- 100mA
- Voltage Rated Ac
- 125V
- Ingress Protection
- IP62
- Terminal
- Screw
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Ambalaj
- Bulk
- HTS Kodu
- 8536.50.70.00
- Release Force
- 28gf
- Çalışma Sıcaklığı
- -15°C~80°C
- Parça Durumu
- Active
- Fabrika Tedarik Süresi
- 2 Weeks
- Montaj
- Chassis Mount, Panel
- Mechanical Life
- 20,000,000 Cycles
- Current Rating Amps
- 100mA AC/DC
- Contact Ac Max Rating R Load
- .1A@125VAC
- Differential Travel
- 0.031 (0.8mm)
- Operating Force
- 200gf
- Voltage Rated Dc
- 30V
