Specifications
- Housing Material
- PBT
- Uzunluk
- 5.1mm
- Kurşunsuz Kodu
- yes
- Orientation
- Straight
- Contact Shape
- Square
- Mating Post Length
- 4.3mm
- Housing Color
- Black
- Sıra Sayısı
- 1
- Depth
- 2.5mm
- Pozisyon Sayısı
- 2
- Lead Length
- 2.8mm
- Contact Gender
- Male
- Insulation Materials
- Polyphenylene Sulfide (PPS), Glass Filled
- Contact Length Post
- 0.110 2.79mm
- Mil Conformance
- NO
- Contact Type
- Male Pin
- Parça Durumu
- Obsolete
- Contact Finish Mating
- Gold
- Contact Lengthmating
- 0.169 4.30mm
- ECCN Kodu
- EAR99
- Overall Contact Length
- 0.339 8.60mm
- Montaj Tipi
- Through Hole
- Seri
- XJ8
- Material Flammability Rating
- UL94 V-0
- Max Voltage Rating Ac
- 300V
- RoHS Durumu
- RoHS Compliant
- Iec Conformance
- NO
- Fabrika Tedarik Süresi
- 7 Weeks
- Pitch Mating
- 0.100 2.54mm
- Contact Resistance
- 20mOhm
- Montaj
- Through Hole
- JESD-609 Kodu
- e4
- Contact Finish Thickness Mating
- 5.90μin 0.150μm
- Yükseklik
- 8.6mm
- Ambalaj
- Bulk
- Din Conformance
- NO
- Çalışma Sıcaklığı
- -55°C~105°C
- Max Current Rating
- 2A
- Fastening Type
- Push-Pull
- Terminal
- Solder
