Volume pricing
- 1+ pcs$26.94
- 10+ pcs$25.42
- 100+ pcs$23.98
- 500+ pcs$22.62
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Release Force
- 114gf
- Actuator Material
- Stainless Steel
- Uzunluk
- 49.2mm
- Body Height
- 24.2mm
- Contact Materials
- Silver
- Actuator Type
- Round (Pin Plunger)
- Switch Function
- On-Mom
- Orientation
- Straight
- Circuit
- SPDT
- Akım Değeri
- 10A
- Max Voltage Rating Dc
- 250V
- Terminal Stili
- Screw Terminal
- Weight
- 63g
- Montaj
- Panel, Screw
- Max Current Rating
- 10A
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Differential Travel
- 0.007 (0.18mm)
- ECCN Kodu
- EAR99
- Fabrika Tedarik Süresi
- 2 Weeks
- HTS Kodu
- 8536.50.70.00
- Current Rating Amps
- 10A DC
- Operating Force
- 510gf
- Depth
- 17.45mm
- Switch Type
- SNAP ACTING/LIMIT SWITCH
- Overtravel
- 0.217 (5.5mm)
- Kurşunsuz
- Lead Free
- Yayın Yılı
- 2005
- Pretravelmax
- 0.9 mm
- Ingress Protection
- IP00
- Terminal
- Screw
- Çalışma Sıcaklığı
- -25°C~80°C
- Mechanical Life
- 1,000,000 Cycles
- Voltage Rated Dc
- 30V
- Operating Position
- 0.859 (21.8mm)
- Contact Dc Max Rating R Load
- 10A@125VDC
- RoHS Durumu
- RoHS Compliant
- Electricallife
- 100,000 Cycles
- Pretravel
- 0.035 (0.9mm)
- REACH Uyumluluk Kodu
- unknown
- Montaj Tipi
- Panel Mount
