Specifications
- Actuator Travel
- 1.03 mm
- Body Length Or Diameter
- 49.2mm
- Montaj
- Chassis Mount, Panel
- Differential Travel
- 0.007 (0.18mm)
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- ECCN Kodu
- EAR99
- Fabrika Tedarik Süresi
- 2 Weeks
- Current Rating Amps
- 10A DC
- HTS Kodu
- 8536.50.70.00
- Body Breadth
- 17.45 mm
- Operating Force
- 510gf
- Release Force
- 114gf
- Body Height
- 24.2mm
- Actuator Type
- Round (Pin Plunger)
- Switch Function
- On-Mom
- Akım Değeri
- 10A
- Circuit
- SPDT
- Terminal Stili
- Screw Terminal
- RoHS Durumu
- RoHS Compliant
- Electricallife
- 100,000 Cycles
- REACH Uyumluluk Kodu
- unknown
- Contact Voltagedcmax
- 125V
- Pretravel
- 0.035 (0.9mm)
- Montaj Tipi
- Chassis Mount
- Parça Durumu
- Active
- Ambalaj
- Tray
- Seri
- X
- Switch Type
- SNAP ACTING/LIMIT SWITCH
- Overtravel
- 0.005 (0.13mm)
- Kurşunsuz
- Lead Free
- Ingress Protection
- IP00
- Pretravelmax
- 0.9 mm
- Yayın Yılı
- 2005
- Terminal
- Screw
- Çalışma Sıcaklığı
- -25°C~80°C
- Mechanical Life
- 1,000,000 Cycles
- Operating Position
- 0.625 (15.9mm)
- Voltage Rated Dc
- 30V
- Contact Dc Max Rating R Load
- 10A@125VDC
