Specifications
- Actuator Type
- Roller Plunger
- Operating Position
- 1.695 (43.05mm)
- Contact Ac Max Rating R Load
- .1A@125VAC
- Montaj
- Panel, Screw
- Contact Currentdcmax
- 0.1A
- Pretravel
- 0.060 (1.5mm)
- Seri
- SHL
- ECCN Kodu
- EAR99
- Voltage Rated Ac
- 125V
- Contact Currentacmax
- 0.1A
- Electricallife
- 500,000 Cycles
- Montaj Tipi
- Panel Mount
- RoHS Durumu
- RoHS Compliant
- Contact Current Rating
- 10A
- Fabrika Tedarik Süresi
- 2 Weeks
- Throw Configuration
- SPDT, SPST
- Max Voltage Rating Ac
- 125V
- Differential Travel
- 0.020 (0.5mm)
- Reach Svhc
- Unknown
- Contact Dc Max Rating R Load
- .1A@30VDC
- Switch Function
- On-Mom
- Operating Force
- 1000gf
- Terminal
- Screw
- HTS Kodu
- 8536.50.70.00
- Switch Type
- SNAP ACTING/LIMIT SWITCH
- Contact Resistance
- 15mOhm
- Yayın Yılı
- 2004
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Ambalaj
- Bulk
- Circuit
- SPDT
- Pretravelmax
- 1.5 mm
- Uzunluk
- 73.5mm
- Depth
- 17.5mm
- Housing Material
- Zinc
- Voltage Rated Dc
- 30V
- Current Rating Amps
- 100mA AC/DC
- Parça Durumu
- Active
- Ingress Protection
- IP67 - Dust Tight, Waterproof
- Onay Kuruluşu
- CSA, TUV, UL
- Ratings
- Dust Tight, IP67, Waterproof
