Specifications
- Terminal
- Screw
- Max Voltage Rating Dc
- 250V
- Ambalaj
- Tray
- Contact Ac Max Rating R Load
- 10A@250VAC
- Montaj Tipi
- Chassis Mount
- Actuator Travel
- 1.83 mm
- Genişlik
- 17.45mm
- Contact Materials
- Silver
- Release Force
- 57gf
- Contact Current Rating
- 10A
- Onay Kuruluşu
- CSA, UL
- HTS Kodu
- 8536.50.70.00
- Montaj
- Chassis Mount, Panel, Screw
- Parça Durumu
- Active
- Seri
- DZ
- Pretravel
- 0.067 (1.7mm)
- Circuit
- DPDT
- Current Rating Amps
- 10A AC/DC
- Mechanical Life
- 1,000,000 Cycles
- Weight
- 50g
- Kurşunsuz
- Lead Free
- Actuator Type
- Round (Pin Plunger)
- Switch Function
- On-Mom
- Contact Dc Max Rating R Load
- 10A@30VDC
- Electricallife
- 500,000 Cycles
- RoHS Durumu
- RoHS Compliant
- Overtravel
- 0.005 (0.13mm)
- Depth
- 23.1mm
- Voltage Rated Dc
- 30V
- Yayın Yılı
- 2005
- ECCN Kodu
- EAR99
- Switch Type
- SNAP ACTING/LIMIT SWITCH
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Çalışma Sıcaklığı
- -25°C~80°C
- Voltage Rated Ac
- 250V
- Akım Değeri
- 10A
- Terminal Stili
- Screw Terminal
- Uzunluk
- 49.2mm
- Ingress Protection
- IP00
- Pretravelmax
- 1.7 mm
