Specifications
- Throw Configuration
- SPST
- Ingress Protection
- IP40
- Fabrika Tedarik Süresi
- 2 Weeks
- Contact Currentacmax
- 0.01A
- Body Height
- 18mm
- RoHS Durumu
- RoHS Compliant
- ECCN Kodu
- EAR99
- Switch Type
- SNAP ACTING/LIMIT SWITCH
- Circuit
- SPST-NC
- Operating Position
- 0.079 (2.0mm)
- Electricallife
- 1,000,000 Cycles
- Çalışma Sıcaklığı
- -20°C~75°C
- Switch Function
- On-Mom
- Mechanical Life
- 10,000,000 Cycles
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Yayın Yılı
- 2002
- Parça Durumu
- Active
- Body Length Or Diameter
- 5mm
- Voltage Rated Ac
- 24V
- Terminal
- Cable Leads
- Özellikler
- Cable Length 1m
- Actuator Travel
- 1.5 mm
- Contact Currentdcmax
- 0.01A
- Current Rating Amps
- 10mA AC/DC
- Contact Resistance
- 800mOhm
- Max Voltage Rating Dc
- 12V
- Radyasyon Dayanımı
- No
- Ambalaj
- Bulk
- Akım Değeri
- 10mA
- Montaj Tipi
- Panel Mount
- Overtravel
- 0.060 (1.5mm)
- Montaj
- Panel
- Voltage Rated Dc
- 12V
- HTS Kodu
- 8536.50.70.00
- Seri
- D5A
- Terminal Stili
- Cable Leads
- Actuator Type
- Round (Pin Plunger)
- Max Voltage Rating Ac
- 24V
- Orientation
- Straight
- Pin Sayısı
- 2
