Specifications
- Radyasyon Dayanımı
- No
- Max Voltage Rating Dc
- 12V
- Contact Resistance
- 800mOhm
- Current Rating Amps
- 10mA AC/DC
- Contact Currentdcmax
- 0.01A
- Akım Değeri
- 10mA
- Montaj
- Panel
- Overtravel
- 0.060 (1.5mm)
- Montaj Tipi
- Panel Mount
- Ambalaj
- Bulk
- Terminal Stili
- Cable Leads
- Seri
- D5A
- HTS Kodu
- 8536.50.70.00
- Voltage Rated Dc
- 12V
- Pin Sayısı
- 2
- Operating Force
- 30gf
- Differential Travel
- 0.0002 (0.005mm)
- Orientation
- Straight
- Max Voltage Rating Ac
- 24V
- Actuator Type
- Round (Pin Plunger)
- RoHS Durumu
- RoHS Compliant
- Circuit
- SPST-NC
- Switch Type
- SNAP ACTING/LIMIT SWITCH
- ECCN Kodu
- EAR99
- Body Height
- 18mm
- Contact Currentacmax
- 0.01A
- Fabrika Tedarik Süresi
- 2 Weeks
- Throw Configuration
- SPST
- Ingress Protection
- IP40
- Switch Function
- On-Mom
- Çalışma Sıcaklığı
- -20°C~75°C
- Yayın Yılı
- 2006
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Mechanical Life
- 10,000,000 Cycles
- Electricallife
- 1,000,000 Cycles
- Operating Position
- 0.079 (2.0mm)
- Terminal
- Cable Leads
- Voltage Rated Ac
- 24V
- Özellikler
- Cable Length 1m
- Parça Durumu
- Active
