Specifications
- REACH Uyumluluk Kodu
- unknown
- Yayın Yılı
- 2006
- Montaj
- Chassis Mount, Panel, Screw
- Switch Type
- SNAP ACTING/LIMIT SWITCH
- ECCN Kodu
- EAR99
- Current Rating Amps
- 5A AC/DC
- Fabrika Tedarik Süresi
- 2 Weeks
- Depth
- 18mm
- Contact Resistance
- 15mOhm
- Terminal Stili
- Screw Terminal
- Release Force
- 500gf
- Electricallife
- 500,000 Cycles
- Montaj Tipi
- Panel Mount
- Parça Durumu
- Active
- Differential Travel
- 0.004 (0.1mm)
- Actuator Type
- Cross Roller Plunger
- Max Voltage Rating Ac
- 250V
- Ingress Protection
- IP67 - Dust Tight, Waterproof
- Uzunluk
- 57mm
- Seri
- D4E-xN
- Circuit
- SPDT
- Switch Function
- On-Mom
- Terminal
- Screw
- Operating Force
- 1200gf
- Mechanical Life
- 10,000,000 Cycles
- Yükseklik
- 61.3mm
- Voltage Rated Dc
- 30V
- Operating Position
- 1.235 (31.4mm)
- Akım Değeri
- 5A
- Ambalaj
- Bulk
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- RoHS Durumu
- RoHS Compliant
- Orientation
- Straight
- Max Voltage Rating Dc
- 250V
- Pretravel
- 0.060 (1.5mm)
- Onay Kuruluşu
- CCC, CSA, TUV, UL
- Voltage Rated Ac
- 125V
- Overtravel
- 0.118 (3.0mm)
- Ratings
- Dust Tight, IP67, Waterproof
- Çalışma Sıcaklığı
- -10°C~80°C
