Specifications
- Body Height
- 49mm
- Operating Position
- 1.350 (34.3mm)
- Akım Değeri
- 100mA
- Terminal
- Cable Leads
- Operating Force
- 1800gf
- Mechanical Life
- 10,000,000 Cycles
- Contact Currentacmax
- 0.1A
- Voltage Rated Dc
- 30V
- Body Length Or Diameter
- 40mm
- Pretravel
- 0.071 (1.8mm)
- Özellikler
- Oil Resistant Cable 3m
- Voltage Rated Ac
- 125V
- Overtravel
- 0.118 (3.0mm)
- Ratings
- Dust Tight, IP67, Waterproof
- Çalışma Sıcaklığı
- -10°C~70°C
- HTS Kodu
- 8536.50.70.00
- Ambalaj
- Bulk
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- RoHS Durumu
- RoHS Compliant
- ECCN Kodu
- EAR99
- Fabrika Tedarik Süresi
- 2 Weeks
- Current Rating Amps
- 100mA AC/DC
- Terminal Stili
- Cable Leads
- Release Force
- 450gf
- Actuator Travel
- 4.8 mm
- Electricallife
- 200,000 Cycles
- REACH Uyumluluk Kodu
- unknown
- Yayın Yılı
- 2007
- Montaj
- Chassis Mount
- Pretravelmax
- 1.8 mm
- Switch Type
- SNAP ACTING/LIMIT SWITCH
- Actuator Type
- Cross Roller Plunger
- Differential Travel
- 0.008 (0.2mm)
- Ingress Protection
- IP67 - Dust Tight, Waterproof
- Seri
- D4C
- Switch Function
- On-Mom
- Circuit
- SPDT
- Parça Durumu
- Active
- Montaj Tipi
- Chassis Mount
- Contact Currentdcmax
- 0.1A
