Volume pricing
- 1+ pcs$120.44
- 10+ pcs$113.63
- 100+ pcs$107.19
- 500+ pcs$101.13
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Montaj
- Chassis Mount, Panel, Screw
- Yayın Yılı
- 2006
- Switch Type
- SNAP ACTING/LIMIT SWITCH
- Terminal Stili
- Cable Leads
- Depth
- 16mm
- Current Rating Amps
- 5A AC 4A DC
- Fabrika Tedarik Süresi
- 2 Weeks
- ECCN Kodu
- EAR99
- Electricallife
- 200,000 Cycles
- Actuator Travel
- 4.8 mm
- Release Force
- 450gf
- Contact Currentdcmax
- 4A
- Montaj Tipi
- Chassis Mount
- Parça Durumu
- Active
- Contact Ac Max Rating R Load
- 5A@250VAC
- Ingress Protection
- IP67 - Dust Tight, Waterproof
- Actuator Type
- Round (Pin Plunger)
- Max Voltage Rating Ac
- 250V
- Differential Travel
- 0.008 (0.2mm)
- Switch Function
- On-Mom
- Circuit
- SPDT
- Seri
- D4C
- Throw Configuration
- DPDT, SPDT
- Uzunluk
- 49mm
- Operating Force
- 1800gf
- Mechanical Life
- 10,000,000 Cycles
- Contact Dc Max Rating R Load
- 4A@30VDC
- Additional Feature
- ELECTRICAL LIFE IS CALCULATED AT AN OPERATING TEMPERATURE 5 DEGREE TO 35 DEGREE
- Terminal
- Cable Leads
- Voltage Rated Dc
- 30V
- Contact Currentacmax
- 5A
- Number Of Poles
- 1
- Akım Değeri
- 5A
- Operating Position
- 0.980 (24.9mm)
- RoHS Durumu
- RoHS Compliant
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- HTS Kodu
- 8536.50.70.00
- Ambalaj
- Bulk
- Genişlik
- 40mm
- Reach Svhc
- Unknown
