Specifications
- Release Force
- 150gf
- Electricallife
- 500,000 Cycles
- ECCN Kodu
- EAR99
- Current Rating Amps
- 10A AC 6A DC
- Terminal Stili
- Screw Terminal
- Contact Voltagedcmax
- 14V
- Switch Type
- SNAP ACTING/LIMIT SWITCH
- REACH Uyumluluk Kodu
- unknown
- Yayın Yılı
- 2002
- Montaj
- Chassis Mount
- Throw Configuration
- SPDT
- Seri
- D4B-N
- Circuit
- SPDT (DB/DM)
- Switch Function
- On-Mom
- Differential Travel
- 12°
- Actuator Type
- Side Rotary, Roller
- Ingress Protection
- IP67 - Dust Tight, Waterproof
- Contact Ac Max Rating R Load
- 10A@400VAC
- Body Breadth
- 40 mm
- Montaj Tipi
- Chassis Mount
- Parça Durumu
- Active
- Contact Currentdcmax
- 10A
- Akım Değeri
- 6A
- Contact Voltageacmax
- 400V
- Body Height
- 74mm
- Contact Currentacmax
- 10A
- Voltage Rated Dc
- 30V
- Body Length Or Diameter
- 43mm
- Terminal
- Screw
- Additional Feature
- P.T.= 21 DEG, T.T.= 71 DEG
- Contact Dc Max Rating R Load
- 10A@14VDC
- Mechanical Life
- 30,000,000 Cycles
- Operating Force
- 960gf
- Voltage Rated Ac
- 120V
- Ratings
- Dust Tight, IP67, Waterproof
- Overtravel
- 50°
- Çalışma Sıcaklığı
- -40°C~80°C
- Pretravel
- 21°
- Özellikler
- Stainless Steel Roller
- HTS Kodu
- 8536.50.70.00
