Specifications
- Contact Currentdcmax
- 5A
- Montaj
- Chassis Mount
- Voltage Rated Dc
- 30V
- Ingress Protection
- IP67 - Dust Tight, Waterproof
- Body Height
- 75.5mm
- Circuit
- DPDT (DB/DM)
- ECCN Kodu
- EAR99
- Terminal Stili
- Screw Terminal
- Body Length Or Diameter
- 44mm
- Contact Ac Max Rating R Load
- 5A@125VAC
- Electricallife
- 750,000 Cycles
- Current Rating Amps
- 5A AC 3A DC
- Pretravel
- 15°
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Throw Configuration
- DPDT
- Terminal
- Screw
- Montaj Tipi
- Chassis Mount
- Akım Değeri
- 3A
- Parça Durumu
- Active
- Fabrika Tedarik Süresi
- 2 Weeks
- Switch Function
- On-Mom
- Contact Dc Max Rating R Load
- 5A@14VDC
- Switch Type
- SNAP ACTING/LIMIT SWITCH
- Operating Force
- 150gf
- REACH Uyumluluk Kodu
- unknown
- Body Breadth
- 42 mm
- Çalışma Sıcaklığı
- -20°C~100°C
- Contact Currentacmax
- 5A
- RoHS Durumu
- RoHS Compliant
- Additional Feature
- P.T. = 15 DEG, T.T.= 15 DEG
- HTS Kodu
- 8536.50.70.00
- Contact Voltagedcmax
- 14V
- Ratings
- Dust Tight, IP67, Waterproof
- Voltage Rated Ac
- 125V
- Actuator Type
- Spring, Coil
- Seri
- D4A
- Ambalaj
- Bulk
