Specifications
- Overtravel
- 20°
- Body Height
- 75.5mm
- Circuit
- SPDT (DB/DM)
- ECCN Kodu
- EAR99
- Terminal Stili
- Screw Terminal
- Body Length Or Diameter
- 44mm
- Contact Currentdcmax
- 10A
- Montaj
- Chassis Mount, Panel
- Voltage Rated Dc
- 30V
- Ingress Protection
- IP67 - Dust Tight, Waterproof
- Throw Configuration
- SPDT
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Differential Travel
- 35°
- Terminal
- Screw
- Contact Voltageacmax
- 480V
- Montaj Tipi
- Chassis Mount
- Akım Değeri
- 6A
- Contact Ac Max Rating R Load
- 10A@480VAC
- Electricallife
- 1,000,000 Cycles
- Current Rating Amps
- 10A AC 6A DC
- Pretravel
- 65°
- Özellikler
- Status Indicator
- Body Breadth
- 42 mm
- Çalışma Sıcaklığı
- -10°C~80°C
- Contact Currentacmax
- 10A
- RoHS Durumu
- RoHS Compliant
- Parça Durumu
- Active
- Fabrika Tedarik Süresi
- 2 Weeks
- Switch Function
- On-On
- Switch Type
- SNAP ACTING/LIMIT SWITCH
- Contact Dc Max Rating R Load
- 10A@14VDC
- Operating Force
- 40gfm
- REACH Uyumluluk Kodu
- unknown
- Seri
- D4A
- Ambalaj
- Bulk
- Additional Feature
- P.T. = 15 DEG, D.T. = 5 DEG, T.T.= 20 DEG
- Mechanical Life
- 50,000,000 Cycles
- HTS Kodu
- 8536.50.70.00
- Contact Voltagedcmax
- 14V
- Ratings
- Dust Tight, IP67, Waterproof
