Specifications
- Ratings
- Dust Tight, IP65, Water Resistant
- Pozisyon Sayısı
- 3
- Panel Cutout Dimensions
- Circular - 16.00mm Dia
- Terminal Stili
- Solder, Quick Connect - 0.110 (2.8mm)
- Özellikler
- Bezel - Square
- Contact Currentdcmax
- 3A
- Illumination
- Illuminated
- Contact Current Rating
- 10mA
- Kurşunsuz
- Lead Free
- Yayın Yılı
- 2005
- Lens Color
- Green
- Number Of Switch Sections
- 1
- Mechanical Life
- 250,000 Cycles
- Parça Durumu
- Obsolete
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- ECCN Kodu
- EAR99
- Montaj
- Panel
- Current Rating Amps
- 5A AC 3A DC
- Montaj Tipi
- Panel Mount
- Voltage Rated Dc
- 30V
- REACH Uyumluluk Kodu
- unknown
- Switch Function
- On-On-On
- Seri
- A165W
- Illumination Type
- Illuminated, LED
- Akım Değeri
- 3A
- Ingress Protection
- IP65 - Dust Tight, Oil and Water Resistant
- Depth Behind Flange
- 28.50mm
- Body Length Or Diameter
- 18mm
- Body Breadth
- 15.8 mm
- Terminal
- Solder
- Onay Kuruluşu
- CCC, cUL, TUV, UL
- Illumination Type Color
- LED, Green
- Illumination Voltage Nominal
- 24VDC
- Tip
- Standard
- Çalışma Sıcaklığı
- -10°C~55°C
- Body Height
- 21.1mm
- Orientation
- Vertical
- RoHS Durumu
- RoHS Compliant
- Contact Ac Max Rating R Load
- 5A@125VAC
- Circuit
- DPDT
