Volume pricing
- 1+ pcs$44.19
- 10+ pcs$41.69
- 100+ pcs$39.33
- 500+ pcs$37.10
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Illumination Type
- LED
- Akım Değeri
- 5A
- Number Of Poles
- 2
- Ingress Protection
- IP66 - Dust Tight, Oil and Water Resistant
- Insulation Resistance
- 100MOhm
- Terminal
- Solder
- Tip
- Standard, Illuminated
- Çalışma Sıcaklığı
- -10°C~55°C
- Illumination Voltage Nominal
- 24VDC
- Onay Kuruluşu
- UL
- Illumination Type Color
- LED, White
- Color Actuatorcap
- White
- RoHS Durumu
- RoHS Compliant
- Max Voltage Rating Ac
- 250V
- Orientation
- Straight
- Max Current Rating
- 5A
- Voltage Rated Ac
- 125V
- Circuit
- DPDT
- Electricallife
- 100,000 Cycles
- Contact Materials
- Silver
- Panel Cutout Dimensions
- Circular - 16.00mm Dia
- Ratings
- Dust Tight, IP65, Water Resistant
- Body Material
- Polycarbonate, Resin
- Terminal Stili
- Solder, Quick Connect - 0.110 (2.8mm)
- Contact Current Rating
- 10mA
- Kurşunsuz
- Lead Free
- Yayın Yılı
- 2001
- Uzunluk
- 24mm
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Depth
- 18mm
- ECCN Kodu
- EAR99
- Max Voltage Rating Dc
- 30V
- Mechanical Life
- 2,000,000 Cycles
- Parça Durumu
- Active
- Fabrika Tedarik Süresi
- 3 Weeks
- Ambalaj
- Bulk
- Actuator Length
- 3.5mm
- Current Rating Amps
- 5A AC
- Montaj
- Front, Panel, Snap in
- REACH Uyumluluk Kodu
- unknown
