Volume pricing
- 1+ pcs$22.31
- 10+ pcs$21.05
- 100+ pcs$19.86
- 500+ pcs$18.73
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Max Voltage Rating Ac
- 250V
- Actuator Length
- 3.5mm
- Terminal
- Solder
- Actuator Type
- Square, Button
- Fabrika Tedarik Süresi
- 3 Weeks
- Insulation Resistance
- 100MOhm
- Body Material
- Polycarbonate, Resin
- Life Cycles
- 100000 cycles
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Onay Kuruluşu
- UL
- Voltage Rated Ac
- 125V
- Voltage Rated Dc
- 30V
- Montaj
- Front, Panel, Snap in
- Terminal Stili
- Solder, Quick Connect - 0.110 (2.8mm)
- Illumination Voltage Nominal
- 24VDC
- Seri
- A16
- Number Of Poles
- 2
- Yayın Yılı
- 2001
- RoHS Durumu
- RoHS Compliant
- Panel Cutout Dimensions
- Circular - 16.00mm Dia
- Contact Currentacmax
- 5A
- Operating Forcemax
- 4.91 N
- Current Rating Amps
- 5A AC
- Contact Dc Max Rating R Load
- 3A@30VDC
- Max Voltage Rating Dc
- 30V
- Contact Materials
- Silver
- Max Current Rating
- 5A
- Body Breadth
- 15.8 mm
- Depth
- 18mm
- Çalışma Sıcaklığı
- -10°C~55°C
- Orientation
- Straight
- Akım Değeri
- 5A
- Illumination Type
- LED
- Circuit
- DPDT
- Contact Currentdcmax
- 3A
- Tip
- Standard, Illuminated
- Color Actuatorcap
- Green
- Electricallife
- 100,000 Cycles
- ECCN Kodu
- EAR99
- Kurşunsuz
- Lead Free
