Specifications
- Electricallife
- 100,000 Cycles
- Actuator Type
- Round, Button, Mushroom
- Fabrika Tedarik Süresi
- 3 Weeks
- Tip
- Emergency Stop, Illuminated
- Contact Currentdcmax
- 3A
- Circuit
- DPST-NC
- Terminal
- Quick Connect, Solder
- Illumination Type
- LED
- Akım Değeri
- 5A
- Voltage Rated Ac
- 125V
- Illumination Type Color
- LED, Red
- Head Diameter
- 30 mm
- Montaj Tipi
- Panel Mount, Front
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- ECCN Kodu
- EAR99
- Ratings
- Dust Tight, IP65, Water Resistant
- Body Length Or Diameter
- 18mm
- Ambalaj
- Bulk
- Kurşunsuz
- Lead Free
- Yayın Yılı
- 2005
- Panel Cutout Dimensions
- Circular - 16.00mm Dia
- RoHS Durumu
- RoHS Compliant
- Lens Color
- Red
- Number Of Poles
- 2
- Seri
- A165E
- HTS Kodu
- 8536.50.90.31
- Terminal Stili
- Solder, Quick Connect - 0.110 (2.8mm)
- Illumination Voltage Nominal
- 24VDC
- Voltage Rated Dc
- 24V
- Montaj
- Front, Panel
- Mechanical Life
- 100,000 Cycles
- Contact Voltagedcmax
- 30V
- Ingress Protection
- IP65 - Dust Tight, Water Resistant
- Orientation
- Vertical
- Çalışma Sıcaklığı
- -10°C~55°C
- Max Current Rating
- 5A
- Body Breadth
- 15.8 mm
- Throw Configuration
- DPST, SPST
- Operating Forcemax
- 14.7 N
- Switch Function
- On-Off
