Specifications
- Pin Sayısı
- 6
- Throw Configuration
- DPST
- Electricallife
- 100000 Cycle(s)
- Contact Materials
- Silver
- Terminal Sayısı
- 6
- Radyasyon Dayanımı
- No
- Input Switching Control Type
- Random
- Terminal
- PC Pin
- Operate Time
- 15 ms
- Min. Çalışma Sıcaklığı
- -40°C
- Contact Ac Max Rating R Load
- 3A@250VAC
- Relay Form
- 1 FORM C
- Contact Rating Current
- 3A
- Kurşunsuz
- Lead Free
- Coil Current
- 15mA
- Dielectric Strength Between Open Contacts
- 1000 Vrms
- Max Voltage Rating Ac
- 380V
- Current Rating Max
- 3A
- Genişlik
- 13mm
- Contactoutput Supply Type
- AC/DC
- Coilinput Supply Type
- DC
- Dielectric Strength Between Coil And Contacts
- 5000 Vrms
- Physical Dimension
- 29mm x 13mm x 25.5mm
- Reference Standard
- CSA; SEMKO; TUV; UL; VDE
- Uzunluk
- 29mm
- Relay Action
- MOMENTARY
- Coil Voltage
- 24V
- Power Consumption
- 360mW
- Kurşunsuz Kodu
- yes
- ECCN Kodu
- EAR99
- Contact Dc Max Rating R Load
- 3A@30VDC
- Maks. Çalışma Sıcaklığı
- 70°C
- Coil Type
- Non-Latching
- Coilresistance
- 1.6kOhm
- Fabrika Tedarik Süresi
- 10 Weeks
- Relay Type
- General Purpose
- Coil Voltage Dc
- 24V
- Yükseklik
- 25.5mm
- Max Voltage Rating Dc
- 125V
- Insulation Resistance
- 1000000000Ohm
