Specifications
- Parça Durumu
- Obsolete
- Fet Technology
- METAL-OXIDE SEMICONDUCTOR
- RoHS Durumu
- ROHS3 Compliant
- Transistor Element Material
- SILICON
- Tepe Reflow Süresi (maks. sn)
- 40
- Nem Hassasiyeti (MSL)
- 3 (168 Hours)
- Qualification Status
- Not Qualified
- Kılıf / Paket
- TO-272-8
- ECCN Kodu
- EAR99
- Configuration
- COMMON SOURCE, 2 ELEMENTS
- Ambalaj
- Tape & Reel (TR)
- Nominal Gerilim
- 40V
- Voltage Test
- 12.5V
- JESD-609 Kodu
- e3
- Transistor Type
- LDMOS
- Frekans
- 470MHz
- Polaritychannel Type
- N-CHANNEL
- Yayın Yılı
- 2003
- Current Test
- 800mA
- Tepe Reflow Sıcaklığı (°C)
- 260
- Ds Breakdown Voltagemin
- 40V
- Power Dissipationmax Abs
- 165W
- Jesd30 Code
- R-PDFM-F8
- Yüzey Montaj
- YES
- Terminal Formu
- FLAT
- Temel Parça No
- MRF1570
- Gain
- 11.5dB
- Operating Temperature Max
- 200°C
- Operating Mode
- ENHANCEMENT MODE
- Case Connection
- SOURCE
- Number Of Elements
- 2
- Terminal Kaplaması
- Matte Tin (Sn)
- Transistor Application
- AMPLIFIER
- Power Output
- 70W
- HTS Kodu
- 8541.21.00.75
- Terminal Sayısı
- 8
- Terminal Pozisyonu
- DUAL
