MK26FN2M0VMI18

Specifications

Terminal Sayısı

169

Clock Frequency

50MHz

Nem Hassasiyeti (MSL)

3 (168 Hours)

Terminal Pozisyonu

BOTTOM

Casepackage

MAPBGA

Memory Types

FLASH

Data Converters

A/D 5x12b, 6x16b; D/A 2x12b

Parça Durumu

Active

Schedule B

8542310000, 8542310000|8542310000|8542310000|8542310000|8542310000|8542310000|8542310000|8542310000|8542310000|8542310000|8542310000|8542310000|8542310000|8542310000|8542310000|8542310000|8542310000|8542310000|8542310000|8542310000|8542310000|8542310000|8542310000|85

Yüzey Montaj

YES

Uzunluk

9mm

Program Memory Size

2MB 2M x 8

Core Architecture

ARM

Supply Voltagemax Vsup

3.6V

Frekans

180 MHz

Peripherals

DMA, I2S, LVD, POR, PWM, WDT

Core Size

32-Bit

Pin Sayısı

169

Maks. Çalışma Sıcaklığı

105 °C

Program Memory Type

FLASH

Cpu Family

CORTEX-M4F

Kılıf / Paket

169-LFBGA

Speed

180MHz

Tepe Reflow Süresi (maks. sn)

NOT SPECIFIED

Memory Size

2 MB

Jesd30 Code

S-PBGA-B169

Number Of Ios

116

Power Supplies

1.8/3.3V

ECCN Kodu

3A991.A.2

Connectivity

CANbus, EBI/EMI, I2C, IrDA, SD, SPI, UART/USART, USB, USB OTG

Terminal Adımı

0.65mm

RoHS Durumu

ROHS3 Compliant

RoHS

Compliant

Qualification Status

Not Qualified

Ambalaj

Tray

Genişlik

9mm

Voltage Supply Vccvdd

1.71V~3.6V

Pwm Channels

YES

Oscillator Type

Internal

Dac Channels

YES
