MCF52258CVN66

Specifications

Number Of Ios

96

Yayın Yılı

2004

Seri

MCF5225x

Core Size

32-Bit

Data Converters

A/D 8x12b

Montaj Tipi

Surface Mount

JESD-609 Kodu

e2

Peripherals

DMA, LVD, POR, PWM, WDT

Ambalaj

Tray

Supply Voltagemin Vsup

3V

Voltage Supply Vccvdd

3V~3.6V

Kılıf / Paket

144-LBGA

Qualification Status

Not Qualified

Has Adc

YES

RoHS Durumu

ROHS3 Compliant

Supply Voltagemax Vsup

3.6V

Terminal Pozisyonu

BOTTOM

Dac Channels

NO

Romword

524288

Terminal Kaplaması

TIN COPPER/TIN SILVER

Bit Size

32

Upsucsperipheral Ics Type

MICROCONTROLLER, RISC

Program Memory Type

FLASH

Yüzey Montaj

YES

Ram Size

64K x 8

Terminal Adımı

1mm

Core Processor

Coldfire V2

Uzunluk

13mm

Besleme Gerilimi

3.3V

Power Supplies

3.3V

Connectivity

CANbus, EBI/EMI, Ethernet, I2C, QSPI, UART/USART, USB OTG

Clock Frequency

66MHz

Speed

66MHz

Genişlik

13mm

ECCN Kodu

5A992

Program Memory Size

512KB 512K x 8

Tepe Reflow Süresi (maks. sn)

40

Nem Hassasiyeti (MSL)

3 (168 Hours)

Fabrika Tedarik Süresi

10 Weeks

Parça Durumu

Active
