Specifications
- Besleme Gerilimi
- 4.75V~5.25V
- HTS Kodu
- 8542.39.00.01
- Jesd30 Code
- R-PDSO-G30
- Additional Feature
- ALSO REQUIRES 3 VOLTS SUPPLY
- Besleme Gerilimi
- 5V
- Function
- Driver - Fully Integrated, Control and Power Stage
- Genişlik
- 11mm
- Motor Type Ac Dc
- Brushed DC
- Kılıf / Paket
- 30-BSOP (0.433, 11.00mm Width) Exposed Pad
- Montaj Tipi
- Surface Mount
- Ambalaj
- Tape & Reel (TR)
- Tepe Reflow Sıcaklığı (°C)
- 245
- Temel Parça No
- MC33899
- Terminal Formu
- GULL WING
- Terminal Sayısı
- 30
- Output Configuration
- Half Bridge (2)
- RoHS Durumu
- ROHS3 Compliant
- Supply Voltagemin Vsup
- 4.75V
- Parça Durumu
- Obsolete
- Qualification Status
- Not Qualified
- Analog Ic Other Type
- BRUSH DC MOTOR CONTROLLER
- Interface
- SPI
- Uzunluk
- 15.9mm
- Nem Hassasiyeti (MSL)
- 3 (168 Hours)
- Çalışma Sıcaklığı
- -40°C~150°C TJ
- Yayın Yılı
- 2006
- Tepe Reflow Süresi (maks. sn)
- 30
- ECCN Kodu
- EAR99
- Power Supplies
- 3.35V
- Voltage Load
- 6V~26.5V
- Applications
- General Purpose
- Maks. Oturma Yüksekliği
- 3.4mm
- Supply Voltagemax Vsup
- 5.25V
- Terminal Pozisyonu
- DUAL
- Terminal Adımı
- 0.8mm
- Yüzey Montaj
- YES
- REACH Uyumluluk Kodu
- not_compliant
