DSP56F807PY80E

Specifications

Yayın Yılı

1998

Number Of Ios

32

Montaj Tipi

Surface Mount

Barrel Shifter

YES

JESD-609 Kodu

e3

Internal Bus Architecture

MULTIPLE

Core Size

16-Bit

Data Converters

A/D 16x12b

Peripherals

POR, PWM, WDT

Seri

56F8xx

Format

FIXED POINT

Kılıf / Paket

160-LQFP

Voltage Supply Vccvdd

3V~3.6V

Supply Voltagemin Vsup

3V

Ambalaj

Tray

Supply Voltagemax Vsup

3.6V

Qualification Status

Not Qualified

RoHS Durumu

ROHS3 Compliant

Terminal Kaplaması

Matte Tin (Sn)

Terminal Pozisyonu

QUAD

Bit Size

16

Upsucsperipheral Ics Type

DIGITAL SIGNAL PROCESSOR, OTHER

Boundary Scan

YES

Core Processor

56800

Program Memory Type

FLASH

Yüzey Montaj

YES

Ram Size

4K x 16

Address Bus Width

16

Terminal Adımı

0.5mm

Maks. Oturma Yüksekliği

1.6mm

Besleme Gerilimi

3.3V

Uzunluk

24mm

Power Supplies

3.3V

Clock Frequency

80MHz

Connectivity

CANbus, EBI/EMI, SCI, SPI

Program Memory Size

120KB 60K x 16

ECCN Kodu

3A991.A.2

Speed

80MHz

Genişlik

24mm

Fabrika Tedarik Süresi

10 Weeks
