Volume pricing
- 1+ pcs$20.57
- 10+ pcs$19.41
- 100+ pcs$18.31
- 500+ pcs$17.27
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Boyut / Ölçü
- Square - 119mm Lx119mm H
- Housing Material
- Plastic
- Static Pressure
- 0.088 in H2O (21.9 Pa)
- Depth
- 119mm
- Noise
- 29.0 dB
- Çalışma Sıcaklığı
- 14~158°F -10°C~70°C
- Lifetime Temp
- 100000 Hrs @ 25°C
- Güç (Watt)
- 1.92W
- Material Frame
- Plastic
- Yükseklik
- 32mm
- Radyasyon Dayanımı
- No
- Nominal Gerilim
- 12VDC
- Rpm
- 1600 RPM
- Genişlik
- 32.00mm
- Kurşunsuz
- Lead Free
- Voltage Range
- 6V~13.8VDC
- Max Power Dissipation
- 1.92W
- Fabrika Tedarik Süresi
- 18 Weeks
- Min. Çalışma Sıcaklığı
- 14°C
- Uzunluk
- 119mm
- Fan Type
- Tubeaxial
- Parça Durumu
- Active
- Seri
- 4712KL
- Current Rating Amps
- 0.160A
- Yayın Yılı
- 2005
- Material Blade
- Plastic
- Onay Kuruluşu
- CE, CSA, UL, VDE
- Voltage Rated Dc
- 12V
- Akım Değeri
- 160mA
- Life Hours
- 100000 hours
- Power Rating
- 1.92W
- RoHS Durumu
- RoHS Compliant
- Bearing Type
- Ball
- Maks. Çalışma Sıcaklığı
- 158°C
- Terminal
- 2 Wire Leads
- Weight
- 0.529lb 239.95g
- Nem Hassasiyeti (MSL)
- Not Applicable
- Kılıf / Paket
- Axial
