Specifications
- Yayın Yılı
- 2004
- Genişlik
- 25.50mm
- Max Power Dissipation
- 1.92W
- Akım Değeri
- 80mA
- Nem Hassasiyeti (MSL)
- Not Applicable
- Parça Durumu
- Obsolete
- Static Pressure
- 0.072 in H2O (17.9 Pa)
- Material Blade
- Plastic
- Lifetime Temp
- 100000 Hrs @ 25°C
- Current Rating Amps
- 0.080A
- RoHS Durumu
- RoHS Compliant
- Bearing Type
- Ball
- Onay Kuruluşu
- CE, CSA, UL, VDE
- Çalışma Sıcaklığı
- 14~158°F -10°C~70°C
- Material Frame
- Plastic
- Noise
- 27.0 dB
- Rpm
- 1600 RPM
- Güç (Watt)
- 1.92W
- Boyut / Ölçü
- Square - 119mm Lx119mm H
- Terminal
- 3 Wire Leads
- Min. Çalışma Sıcaklığı
- 14°C
- Fan Type
- Tubeaxial
- Maks. Çalışma Sıcaklığı
- 158°C
- Nominal Gerilim
- 24VDC
- Voltage Range
- 10V~27.6VDC
- Kılıf / Paket
- Axial
- Seri
- 4710KL
- Özellikler
- Speed Sensor (Tach)
- Weight
- 0.397lb 180.08g
