Specifications
- Kılıf / Paket
- Axial
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Boyut / Ölçü
- Square - 92mm Lx92mm H
- Onay Kuruluşu
- CE, UL, VDE
- Akım Değeri
- 240mA
- Çalışma Sıcaklığı
- 14~158°F -10°C~70°C
- Terminal
- 3 Wire Leads
- Material Frame
- Plastic
- Life Hours
- 100000 hours
- Static Pressure
- 0.261 in H2O (65.0 Pa)
- Seri
- 09225VA
- Bearing Type
- Ball
- Rpm
- 3600 RPM
- Fan Type
- Tubeaxial
- Current Rating Amps
- 0.240A
- Weight
- 0.298lb 135.17g
- Noise
- 38.5 dB(A)
- RoHS Durumu
- RoHS Compliant
- Parça Durumu
- Obsolete
- Voltage Range
- 7V~13.8VDC
- Lifetime Temp
- 100000 Hrs @ 25°C
- Özellikler
- Locked Rotor Sensor
- Yayın Yılı
- 2009
- Nominal Gerilim
- 12VDC
- Max Power Dissipation
- 2.88W
