Volume pricing
- 1+ pcs$43.55
- 10+ pcs$41.08
- 100+ pcs$38.76
- 500+ pcs$36.56
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Electricallife
- 15,000 Cycles
- Voltage Rated Dc
- 30V
- Montaj Tipi
- Panel Mount
- Özellikler
- Epoxy Sealed Terminals
- Flammability Rating
- UL94 V-0
- Bushing Thread
- M12 x 1
- Actuator Type
- Standard Round
- Housing Material
- Polyamide
- Circuit
- DPDT
- Panel Cutout Dimensions
- Circular - 12.50mm Dia
- Contact Resistance
- 30mOhm
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Ratings
- Dust Tight, IP67, Waterproof
- Contact Current Rating
- 10A
- Kurşunsuz
- Contains Lead
- Parça Durumu
- Active
- Yayın Yılı
- 2006
- Kurşunsuz Kodu
- yes
- Illumination
- Non-Illuminated
- Switch Function
- On-Off-On
- Seri
- WT
- JESD-609 Kodu
- e3
- Current Rating Amps
- 10A AC/DC
- Contact Materials
- Copper
- Number Of Poles
- 2
- Insulation Resistance
- 200MOhm
- Actuator Material
- Brass, Chrome Plated
- Life Cycles
- 15000 cycles
- Terminal Kaplaması
- Tin (Sn)
- Voltage Rated Ac
- 125V
- Fabrika Tedarik Süresi
- 16 Weeks
- Yükseklik
- 32.11mm
- Çalışma Sıcaklığı
- -30°C~70°C
- Pozisyon Sayısı
- 3
- RoHS Durumu
- ROHS3 Compliant
- Ambalaj
- Bulk
- Actuator Length
- 17.50mm
- Orientation
- Vertical
- Ingress Protection
- IP67 - Dust Tight, Waterproof
- Switch Type
- TOGGLE SWITCH
