Volume pricing
- 1+ pcs$13.79
- 10+ pcs$13.01
- 100+ pcs$12.28
- 500+ pcs$11.58
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Illumination
- Non-Illuminated
- Kurşunsuz Kodu
- yes
- Contact Materials
- Silver
- Number Of Poles
- 1
- Seri
- WT
- Circuit
- SPST
- Actuator Type
- Standard Round
- Montaj Tipi
- Panel Mount
- Voltage Rated Dc
- 30V
- Özellikler
- Epoxy Sealed Terminals
- Ratings
- Dust Tight, IP67, Waterproof
- Contact Current Rating
- 10A
- Switch Type
- TOGGLE SWITCH
- Ingress Protection
- IP67 - Dust Tight, Waterproof
- Akım Değeri
- 10A
- Terminal Stili
- Screw Terminal
- Reach Svhc
- No SVHC
- Max Voltage Rating Ac
- 250V
- Illumination Type
- Illuminated, Non-Illuminated
- Fabrika Tedarik Süresi
- 9 Weeks
- Voltage Rated Ac
- 125V
- Pozisyon Sayısı
- 2
- Çalışma Sıcaklığı
- -30°C~70°C
- Genişlik
- 19.4mm
- Actuator Material
- Brass, Chrome Plated
- Uzunluk
- 28.8mm
- Actuator Length
- 17.50mm
- Orientation
- Vertical
- RoHS Durumu
- ROHS3 Compliant
- Switch Function
- On-Off
- Max Voltage Rating Dc
- 30V
- Yayın Yılı
- 2012
- Parça Durumu
- Active
- Kurşunsuz
- Lead Free
- Current Rating Amps
- 10A AC/DC
- JESD-609 Kodu
- e3
- Depth
- 19.4mm
- Housing Material
- Resin
- Bushing Thread
- M12 x 1
- Electricallife
- 15,000 Cycles
