Volume pricing
- 1+ pcs$18.45
- 10+ pcs$17.41
- 100+ pcs$16.42
- 500+ pcs$15.49
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Voltage Rated Dc
- 30V
- Contact Materials
- Silver
- Çalışma Sıcaklığı
- -25°C~85°C
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Ambalaj
- Bulk
- Max Voltage Rating Ac
- 250V
- Uzunluk
- 41mm
- Terminal Stili
- Screw Terminal
- Current Rating Amps
- 15A AC/DC
- Switch Type
- ROCKER SWITCH
- Solderability
- HAND
- Contact Resistance
- 0.01mOhm
- Actuator Marking
- No Marking
- Terminal Material
- BRASS
- Montaj
- Panel, Snap in
- Switch Function
- On-On
- Contact Dc Max Rating R Load
- 15A@30VDC
- Fabrika Tedarik Süresi
- 16 Weeks
- Panel Cutout Dimensions
- Rectangular - 34.20mm x 17.20mm
- Depth
- 24mm
- Orientation
- Vertical
- Actuator Angle
- 24 deg
- Parça Durumu
- Active
- Electricallife
- 15,000 Cycles
- Body Height
- 30.5816mm
- Circuit
- SPDT
- Akım Değeri
- 15A
- Housing Material
- Polyamide
- Max Current Rating
- 15A
- Contact Ac Max Rating R Load
- 15A@250VAC
- Seri
- WR
- Ingress Protection
- IP67 - Dust Tight, Waterproof
- Color Actuatorcap
- Black
- Max Voltage Rating Dc
- 30V
- Insulation Resistance
- 200000000Ohm
- Actuator Type
- Concave (Curved)
- Kurşunsuz Kodu
- yes
- Voltage Rated Ac
- 125V
- Özellikler
- Epoxy Sealed Terminals
- Kurşunsuz
- Lead Free
