Volume pricing
- 1+ pcs$1.61
- 10+ pcs$1.51
- 100+ pcs$1.43
- 500+ pcs$1.35
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Parça Durumu
- Active
- Switch Function
- On-On-On
- Circuit
- DP3T
- Uzunluk
- 15.74mm
- Insulation Resistance
- 100000000Ohm
- Switch Type
- KEYLOCK SWITCH
- Sealing
- MOLDED
- Yayın Yılı
- 2006
- Montaj
- Through Hole
- Electricallife
- 10,000 Cycles
- Solderability
- WAVE
- Key Removable Positions
- All
- Contact Resistance
- 0.08mOhm
- Fabrika Tedarik Süresi
- 16 Weeks
- RoHS Durumu
- ROHS3 Compliant
- Çalışma Sıcaklığı
- -25°C~70°C
- Voltage Rated Ac
- 28V
- Max Voltage Rating Dc
- 28V
- Voltage Rated Dc
- 28V
- Pcb Hole Count
- 12
- Mechanical Life
- 30,000 Cycles
- Terminal
- PC Pin
- JESD-609 Kodu
- e3
- Dielectric Withstanding Voltage
- 500VAC V
- Body Breadth
- 15.24 mm
- Terminal Material
- BRASS
- Bushing Type
- UNTHREADED
- Montaj Tipi
- Through Hole, Right Angle
- Seri
- SK
- Pozisyon Sayısı
- 3
- Terminal Kaplaması
- Tin (Sn)
- Max Voltage Rating Ac
- 28V
- Actuator Type
- Flat Key
- Housing Material
- Polyamide
- Index Angle
- 45 °
- Max Current Rating
- 100mA
- Washability
- SOLVENT
- Depth
- 25.45mm
- Terminal Stili
- PC Pin
- ECCN Kodu
- EAR99
