Volume pricing
- 1+ pcs$13.80
- 10+ pcs$13.02
- 100+ pcs$12.28
- 500+ pcs$11.59
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Contact Materials
- Beryllium Copper
- Bushing Length
- 0.413 inch
- Reach Svhc
- No SVHC
- Contact Finish
- Gold
- Contact Current Rating
- 100mA
- Kurşunsuz
- Lead Free
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- RoHS Durumu
- ROHS3 Compliant
- Contact Timing
- Non-Shorting (BBM)
- Voltage Rated Ac
- 28V
- Kurşunsuz Kodu
- yes
- Insulation Materials
- GLASS FILLED POLYESTER
- Çalışma Sıcaklığı
- -25°C~70°C
- Özellikler
- Process Sealed
- Body Length Or Diameter
- 16.3068mm
- Additional Feature
- KEY REMOVABLE POSITION 1
- Terminal
- PC Pin
- Pcb Hole Count
- 10
- Mechanical Life
- 30,000 Cycles
- Terminal Material
- BRASS
- JESD-609 Kodu
- e3
- Dielectric Withstanding Voltage
- 500VAC V
- Montaj Tipi
- Through Hole, Right Angle
- Parça Durumu
- Active
- Bushing Type
- UNTHREADED
- Terminal Kaplaması
- Tin (Sn)
- Seri
- SK
- Pozisyon Sayısı
- 2
- Switch Function
- On-On
- Circuit
- DPDT
- Actuator Type
- Flat Key
- Insulation Resistance
- 100000000Ohm
- Switch Type
- KEYLOCK SWITCH
- Index Angle
- 90 °
- Yayın Yılı
- 2010
- Montaj
- Through Hole
- Sealing
- MOLDED
- Washability
- SOLVENT
- Key Removable Positions
- 1 only
- Solderability
- WAVE
