Volume pricing
- 1+ pcs$18.54
- 10+ pcs$17.49
- 100+ pcs$16.50
- 500+ pcs$15.56
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- JESD-609 Kodu
- e3
- Dielectric Withstanding Voltage
- 500VAC V
- Terminal Material
- BRASS
- Bushing Type
- UNTHREADED
- Montaj Tipi
- Through Hole, Right Angle
- Parça Durumu
- Active
- Seri
- SK
- Pozisyon Sayısı
- 2
- Circuit
- DPDT
- Switch Function
- On-On
- Terminal Kaplaması
- Tin (Sn)
- Actuator Type
- Flat Key
- Housing Material
- Nylon
- Insulation Resistance
- 100000000Ohm
- Index Angle
- 90 °
- Switch Type
- KEYLOCK SWITCH
- Sealing
- MOLDED
- Yayın Yılı
- 2006
- Montaj
- Through Hole
- Electricallife
- 10,000 Cycles
- Washability
- SOLVENT
- Solderability
- WAVE
- Key Removable Positions
- All
- Terminal Stili
- PC Pin
- Contact Resistance
- 0.08mOhm
- ECCN Kodu
- EAR99
- Fabrika Tedarik Süresi
- 16 Weeks
- Current Rating Amps
- 0.4VA AC/DC
- Length Termination
- 0.138 inch
- Contact Finish
- Gold
- Contact Materials
- Beryllium Copper
- Bushing Length
- 0.413 inch
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Contact Timing
- Non-Shorting (BBM)
- RoHS Durumu
- ROHS3 Compliant
- Çalışma Sıcaklığı
- -25°C~70°C
- Voltage Rated Ac
- 28V
- Kurşunsuz Kodu
- yes
- Özellikler
- Process Sealed
- Body Length Or Diameter
- 16.3068mm
