Specifications
- Dielectric Withstanding Voltage
- 500VAC V
- JESD-609 Kodu
- e3
- Terminal Material
- BRASS
- Body Breadth
- 14.5034 mm
- Bushing Type
- UNTHREADED
- Montaj Tipi
- Through Hole
- Seri
- SK
- Pozisyon Sayısı
- 2
- Terminal Kaplaması
- Tin (Sn)
- Housing Material
- Polyamide
- Max Voltage Rating Ac
- 28V
- Actuator Type
- Flat Key
- Max Current Rating
- 100mA
- Index Angle
- 90 °
- Washability
- SOLVENT
- Terminal Stili
- PC Pin
- Depth
- 14.5mm
- Current Rating Amps
- 0.4VA AC/DC
- ECCN Kodu
- EAR99
- Contact Finish
- Gold
- Orientation
- Vertical
- Contact Materials
- Beryllium Copper
- Contact Timing
- Non-Shorting (BBM)
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Kurşunsuz Kodu
- yes
- Özellikler
- Process Sealed
- Additional Feature
- KEY REMOVABLE POSITION 1 & 3
- Contact Style
- Non-Shorting
- Parça Durumu
- Active
- Switch Function
- On-On
- Circuit
- DPDT
- Uzunluk
- 15.74mm
- Insulation Resistance
- 100000000Ohm
- Switch Type
- KEYLOCK SWITCH
- Sealing
- MOLDED
- Montaj
- Through Hole
- Yayın Yılı
- 2013
- Electricallife
- 10,000 Cycles
- Key Removable Positions
- All
- Solderability
- WAVE
