Volume pricing
- 1+ pcs$20.03
- 10+ pcs$18.90
- 100+ pcs$17.83
- 500+ pcs$16.82
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Circuit
- SP5T
- Contact Timing
- Non-Shorting (BBM)
- Mechanical Life
- 30,000 Cycles
- Contact Dc Max Power Rating R Load
- 0.4VA@28VDC
- Contact Materials
- Beryllium Copper
- RoHS Durumu
- ROHS3 Compliant
- Switch Function
- On-On-On-On-On
- Contact Finish
- Gold
- Electricallife
- 20,000 Cycles
- Body Length Or Diameter
- 11.9888mm
- Contact Resistance
- 0.1mOhm
- Pozisyon Sayısı
- 5
- Housing Material
- Polyester
- Contact Style
- Non-Shorting
- Body Breadth
- 10.16 mm
- Terminal
- PC Pin
- Kurşunsuz
- Contains Lead
- Contact Plating
- Tin
- Montaj
- Through Hole
- Özellikler
- Antistatic, Process Sealed
- Kurşunsuz Kodu
- yes
- Bushing Length
- 0.264 inch
- Seri
- SK
- Current Rating Amps
- 0.4VA AC/DC
- Orientation
- Right Angle
- Fabrika Tedarik Süresi
- 11 Weeks
- Switch Type
- KEYLOCK SWITCH
- Insulation Resistance
- 100000000Ohm
- Pcb Hole Count
- 10
- Parça Durumu
- Active
- Index Angle
- 45 °
- Montaj Tipi
- Through Hole
- Terminal Stili
- PC Pin
- Body Height
- 11.7094mm
- Voltage Rated Ac
- 28V
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Terminal Material
- PHOSPHOR BRONZE
- Voltage Rated Dc
- 28V
- Çalışma Sıcaklığı
- -25°C~70°C
- Yayın Yılı
- 2008
